29/01/00:
You may have noticed a big change to our site. The
frames are now gone (at last) ......A big thanks to Wolfram
Schlich
for
the site design (he also resells our FreeSpeed cards
in Germany). Let me know if you find any bad links in
the html. :)
If
you want to have a look at what a FreeSpeed Card
looks like from any angle, check out this VRML
of a Revision 1 card (you will need the MetaStream
2.1
plugin to run it...it's only 600k to
download, you may want to switch to Direct 3D mode
in the viewer to make it smoother). The VRML model was kindly donated by the3rdaxis,
very nice work!.
More
news on Athlon 550s. We today received three more.
Two were week 52, one was week 01. It seems that
there is no way to tell what you are getting when
buying as both the week 52s were 0.25 micron with
600Mhz cores and 3.6nS cache (even though they were
from the same FAB as our last 750Mhz core one.
The
week 00 FAB 23 Athlon had a 0.18 Core :) , though it was
marked K7650CURBBA we thought it would clock
well......no such luck, this 0.18 core would not go
above 650Mhz whatever we tried (voltage and cache
speeds did nothing). It really does seem that not
all 0.18 cores are the same.
We
have ordered 2 more 550s from another supplier
today, if they turn out to be the elusive 750s, we
will post the suppliers web site. Also if anyone
else knows of a definite source, please let me know.
Fluke |
|
28/01/00:
AMD seem to have made clear their position on
clocking. Basically they say they don't mind any end
user clocking their CPUs, however they do it (including
our FreeSpeed card), but they are clamping down on
anyone who markets pre-modified Athlons.....Nice one
AMD. You can read more about it at
The
Register. Fluke |
|
27/01/00: Update: The two spare 550
0.18 Athlons are sold :( .....We will post here as
soon as we get our hands on more. Fluke |
|
27/01/00: Today I received the two
550 Athlons we had been promised. On first
inspection we were really disappointed. This was the
marking on top of the casing.
K7550MTR51B C
219952603752
We immediately thought....."C",
0.25 micron...........then we decided to inspect the
core to confirm the labeling. This is what was
written on the core
K7750CURAFC
Finally a 750Mhz 0.18 core.......strange
that the "C" was still present on the
casing. The cache speed was 3.6nS which is ok for
clocking.
First thing we did was attach a
FreeSpeed and see what it would do in standard trim.....a
rock solid 800Mhz. Next for the cache.....We
adjusted the cache to 1/3 divider in hope of much
higher speeds to come. (plus I don't really enjoy
resoldering if 2/3s is no good). The result ?
One Athlon reached a rock solid
900Mhz..............the other hit 950Mhz. Both
needed just 1.75v Core and only modest cooling (0.18
cores run very cool). Now with both tests we didn't
have a good PSU handy (only 225W), way to low.....we
suspect with a decent PSU and a K7M Motherboard for
some FSB adjustment 1Ghz must be surely reachable.
All in all it looks like this is the
new overclocking CPU to have. Week 52 550s from FAB
21 :)
btw: We don't not have a definite
supply of these yet, if we do find them, we will
supply the 550s from our website. However, we have
ordered two more from the same batch. We can supply
these to anyone for £215 each (I know this is abit
expensive, but we almost paid that ourselves, so
the extra is just for shipping, we can also mod your
cache if you require it).........the first two
orders secure the 550s :) Fluke |
|
26/01/00: Well, we were meant to get
our 0.18 550 in today, though it turns out it may be
only a 0.25 Core after all. However, the guys over
at www.overclockers.co.uk
have informed everyone on their news pages that they
should have a batch coming in. I feel a pre-order
coming on :)
We now have a banner that anyone can
use to link to us with. Many thanks to the editor of
Super7.net
who constructed it.
We are getting many emails each day
on great core speeds from FreeSpeed overclocked
Athlon 500s. It seems that 850Mhz is being achieved
more and more. This is great news, and does seem to
suggest that AMDs FABs are getting better all the
time at making Athlons. Fluke |
|
25/01/00: Another review is up at
Lostcircuits,
have a look :)
Wolfram
Schlich (one of our German resellers), has
kindly translated our FreeSpeed instructions into
German for us. You can download a copy in MSword
format here.
Fluke |
|
24/01/00: As you all probably
already know, H
Oda has released his software cache adjustment
program. We must congratulate him on some very nice
work.....no-one thought it could be done, however,
for serious overclocking the program is of very
little value.
When your Athlons cache reaches its
limit, your PC usually won't even post at startup
let alone boot all the way into Windows (which this
program requires to run). This means that the
program could only ever solve stability problems in
windows that are a direct result of your cache
becoming unstable......this only probably happens in
very few cases. Even so.......great work!, check it
out.
Anandtech
has just posted a great article on Athlon
overclocking including a nice little review of our
FreeSpeed card. Though our card did not come top (due
to a 10$ higher price than our closest competitor),
we feel our customer service more than makes up for
it and we also include shipping in our prices :))
Hardware-Norge
has also just posted a review of our FreeSpeed Card.
Mike West over at
3DNow!
UK, has informed us of a rather cool guide they
have just written to the superb Asus K7M motherboard........if
you are lucky enough to own one of these boards,
check it out. Fluke |
|
22/01/00: Many of you may of seen the
article over at HardOCP
about AMD apparently taking legal action against
some companies pre-modifying Athlon CPUs. We feel
that this is not in AMDs interest (they themselves
have showcased super cooled, clocked Athlon systems
:\ .......luckily this decision does not effect NM
and our FreeSpeed card as we don't "Modify"
the CPU, just force it to run faster with a small
add-on card ........as always, this news may all be
rumors or a big publicity stunt by some lawyers as
Kyle points out :)) Fluke |
|
20/01/00: First, a few more rumors
concerning the long awaited 0.18 550 Athlons. How
does this sound, 750Mhz Athlon 0.18 core with very
fast cache ???, sounds like a possible candidate for
1Ghz :) . Remember, we have not seen one yet, and
this may all be speculation (though the cache speed
spec seems to have come from a AMD test sample press
release) ...who knows :) , fingers crossed....we
will keep you all posted.
www.gamers.com
have updated there message boards, but in the
process has lost 2 days of our posts, ohh
well.......It does seems however much improved,
though you now have to sign up for membership to
post. There are lots of boards using this service so
it's probably worth it.
Now we all like playing UT and Q2 on
a LAN ?, well, we are going to try and arrange a LAN
party for a few clans. We currently look like we
have three clans interested, including the
guys over at Clan
OCuk.
We hope to book a function room (and
bar of course :) .....and we will help supply the
network and provide a NT server, (though we will
need volunteers to help with admin and networking).
Sounds like a great day/weekends fun.......if
anyone in the UK is interested, please visit the UT
section of
www.clantiger.co.uk
and mail the organizer "Flood", so he can
get the ball rolling :)
Maybe if there is enough interest,
we could provide prizes for the winning clan :)
Fluke |
|
19/01/00: Some good news, we think
we have secured a source for some 550Mhz 0.18 micron
Athlons, and may get a sample next Wednesday. We
will keep you all posted (1Ghz here we come :)
We
have also found out a nice little hack for all you
GEforce owners out there. If you are using the
latest detonator drivers if you add this line to
your registry, it enables Nvidias overclocking
options in your display properties.
This is the location of the hack to add:
[HKEY_LOCAL_MACHINE\SOFTWARE\NVIDIA
Corporation\Global\NvTweak]
Add
this dword:
"CoolBits"=dword:00000003
This
hack was borrowed from Tweak3D |
|
17/01/00: Just got hold of a
Annihilator Pro GEforce256 card today.....though so
far have not seen much of a improvement in
framerates over our old overclocked SDRAM board.
Will try to get some good benchmarks in the next few
days.
Saku has just increased his clock
speed even further now to a staggering 945Mhz
:) .......not far to go till the magic number :).
In the mean time we have got our old
700Mhz Athlon to 900Mhz stable.....but feel it has
alot more in it yet (even on air cooling), I feel a
race to 1Ghz on the way :) Fluke |
|
15/01/00: Hi, Our
Clocking
Competition has just been upped yet again :),
Saku
Lehtonen, one of our resellers, has just
achieved a totally amazing 875Mhz! from his Athlon
500 using the standard 1/2 cache divider.......I
can't see anyone being able to beat this :)
A new site worth a visit is
K7
Core, they are trying to catalog trends and
specs on all Athlon CPUs by week, please visit them
and help the database grow.
Those nice people over at
Montac
have just released two new cooling kits to go with
there excellent Arctic Circle cooler. One kit is a
Cache cooler, comprising of two fan units, and the
other is a back plate cooler to help cool the rear
of your Athlon. Excellent stuff guys!
We have just added a
Press
& User comment page.....please check it out
to find out what people think of FreeSpeed. Fluke |
|
14/01/00: Another FreeSpeed Review
has now been posted at Hardwire.
Could Troy Sandstedt get in touch
with us, your given email address just bounces back
as invalid. Thanks, Fluke |
|
13/01/00: Update: There is now a
rather nice review up at The
Tech Zone, check it out. |
|
13/01/00: We are pleased to say that
we now have had our FreeSpeed cards reviewed by two
Hardware related web sites.
Please check out the reviews at
www.bxboards.com
and www.hwzone.it.
Many more reviews will be following
shortly, we will keep you posted. Fluke |
|
11/01/00: Hi all.....We have just
got this photo from Thumper (one of our first ever
customers). He has solved all his cooling problems
as you can see :). You may ask where can I buy one ?
,well ........you can't, but to make one, just take
4*Celeron 500 coolers, glue together with thermal
adhesive, patch together cooler power leads and you
have a instant NINJA cooler :). Nice work! .
We have got some great news for all
those looking for good Athlon 500 CPUs. We have been
informed by one of our UK resellers, Power
Computing, they now have stock Athlons which are
proving very clockable.
Initial reports are of very high
stable speeds, at standard Core Voltages and very
cool running temps (only needing standard cooling
even when clocked!) .........get your orders in fast
:) Fluke |
|
09/01/00: First, back by popular
demand is our cheesy Bruce Lee piccy :). We'll just
have to live with the possibility of legal action
from the Lee family, though he surely would of used
an Athlon CPU :)
Someone has posted on the msg board
that there is a survey here,
trying to find out cache speed trends in Athlons.
Check it out.
Alot of people have been talking
about cache adjustment, so today we decided to do
some more cache tweaking tests, this time on our
Athlon 700 system to get a good idea where this CPUs
limits were being hit.
Here is the
cache
adjustment table we used
The first interesting thing we
discovered was the cache setting resistors were the
same arrangement as on an Athlon 500 with 1/2
divider (the 700 is meant to be different). Now our
700 until now has only ever been able to reach 800
and has always failed to even post 850. So we
adjusted the cache to 1/3. That did the trick.....a
rock solid 850Mhz at 1.75Vcore. Next for 900 *gulp*.
The system posted fine but would not quite get into
windows, even with a crazy 1.9Vcore.
This proves that on a Athlon 700,
the cache is holding you back around 50Mhz, but
900Mhz seems to be just to much for the core to
handle. (though a later 700 core may have better
luck).
One other interesting note is that
though the system at 850Mhz feels very quick and
most benchmarks confirm this, Quake2 now benches
around 7 FPS slower......this may lead to the
conclusion that it's better to have a 50Mhz slower
CPU than have a faster one with slower cache :)
.....at least as far as games are concerned (this
would be offset if you could reach a extra 100Mhz)
So for all you folks already pushing
your 500s to 850Mhz, think twice about cache
adjustment, 900Mhz may not make as much difference
as you would think.....and you are not going to get
past 900 without sub zero cooling systems :)
Please note that @ 850Mhz, heat is a
real problem on .25 micron CPUs......our Arctic
Circle unit is coping just fine, but is around 50%
warmer than it was at 800Mhz. Fluke |
|
08/01/00: We have just received a
shiny new Arctic Circle Cooler from those nice
people over at Montac.
The unit is just pure quality and is by far the best
cooler we have ever used, keeping our 800Mhz Athlon
almost stone cold :). Check it out, definitely
highly recommended.
If anyone needs the latest shipping
instructions on FreeSpeed fitting, you can download
them here.
Fluke |
|
06/01/00: Our Clocking Competition
has just had its stakes upped. Again Tommi has
squeezed more out of his Athlon 500. He is now
running at 848Mhz......just needed more VIO, Vcore
and Heatsinking. The cool thing is, that he is still
on 1/2 cache divider, so the system must by flying
:) Fluke |
|
05/01/00: A Couple of things worth a
mention from the last few days.....
Many of you may of seen posts around
the net concerning a new program due for release by
the maker of WCPUID. This program will allow
clocking of Athlons through software. After looking
into it for a while I suspect these are its
functions. It will allow FSB adjustment on all
motherboards that support this function (only the
K7M at present I think). It also allows for control
of cache divider. This function sounds cool, but
again I think it will only be available on future
motherboards with a design to support this feature (maybe
the next generation of boards due this quarter). So,
at the end of a day, this utility will be really
handy on next gen boards (remember though that
clocking Athlons really needs Multiplier adjustment
rather than FSB tweaking (which usually results in
major stability problems)
We are currently thinking of a
redesign of this site (I know it's bad :) ......frames
will go, and we should have some cool new logos.
Check out a beta logo here
and let me know what you think. Cheers, Fluke |
|
02/01/00: Just updated the
competition page again. It seems that Tommi has
increased his core speed even more by adding some
better heatsinking on his cache chips. Well done! Fluke |
|
01/01/00: Update: Our free card goes
to Rune Dahl Jørgensen. Well done, no-one spotted
the offer for ages :) |
|
01/01/00: Happy new year everyone!.
To kick off 2k we thought we'd offer
the first order of the millennium FREE OF CHARGE,
offer stands as of 12:08 GMT :). I will update this
page as soon as we get the order. Fluke
News
Archives - May
April
March
February
January December
|
|
Athlon
and AMD are trademarks of Advanced Micro Devices Inc
FreeSpeed Pro and Ninja Micros are both registered
trademarks |
|
|
|
|
|
|
